Installing the Rackmount Server 3-23
Installing the Interlock System
The interlock system ensures rack stability by allowing only one rackmount
server at a time to be pulled out of the rack. The stabilizer bracket and
actuator latch only work in a rack equipped with the interlock system.
8
7
1
1
7
3
6
5
4
2
CAT0154
Figure 3-16. Installing the Interlock System
Compaq Confidential – Need to Know Required
Writer: Robert Young Project: Compaq AlphaServer DS20E System Comments:
Part Number: FR-K8F6W-UA .A01 File Name: d-ch3 Installing a Rack System.doc Last Saved On: 10/4/99 1:25 PM
