Preparing the Rackmount System for the Compaq
Rack
The system is shipped unassembled. Perform the following procedure for
preparing the system for rack installation.
Figure 3-4. Preparing the Rackmount System
Prepare the system as follows:
1. Attach a front mounting bracket
three M3 x 6 mm screws per bracket.
2. Pull the narrow segment (slide mounting bracket)
out of a chassis slide and detach it completely by pressing down the
retainer spring
so that the end of the chassis slide with three holes will stick out past the
system. Secure the chassis slide track to the system with five M4 x 6
mm screws.
3. Repeat the step for the other chassis slide.
Compaq Confidential – Need to Know Required
Writer: Robert Young Project: Compaq AlphaServer DS20E System Comments:
Part Number: FR-K8F6W-UA .A01 File Name: d-ch3 Installing a Rack System.doc Last Saved On: 10/4/99 1:25 PM
4
1
and continuing to pull. Position the chassis slide track
Installing the Rackmount Server 3-5
3
to each side of the system using
of the chassis slide
2
CAT0026
