System Features Module

Part Number: ER-K8F6W-UA .A01 File Name: b-ch1 System Overview.doc Last Saved On: 10/4/99 1:23 PM
The system features module (SFM) monitors environmental conditions in the
system. The SFM supports the two system fans and three power supplies. The
SFM also monitors the state of the CPU fans on the system board. Switch 1
on the switch pack enables the Remote Management Console (RMC). Figure
1-5 shows the SFM key features.
1
2
3
4
5
6
7 8
Figure 1-5. System Features Module
