Managing the System Remotely 10-3

First-Time Setup

To set up the RMC to monitor a system remotely, connect the modem to the
COM1 port at the back of the system, configure the modem port for dial-in,
and dial in.
VGA
4
6
2
1
3
7
5
ENET
8
CAT0017
Figure 10-1. RMC Connections
