Operator Control Panel

The operator control panel (OCP) provides system controls and console
activity indicators (Figure 1-11) on the front of the system enclosure.
3
1
2
6
1 2 3 4
5
4
CAT0018
Figure 1-11. Operator Control Panel (OCP)
The control panel consists of three pushbutton controls, one green LED
indicator for power, a yellow HALT LED, and four LED indicators for
diagnostic faults.
