Table 1-3 describes the main features of the SFM module.
#
Connection
J1
J2
J7
J6
J5
J3
J4
Compaq Confidential – Need to Know Required
Writer: Robert Young Project: DS20E Reference Guide Comments:
Part Number: ER-K8F6W-UA .A01 File Name: b-ch1 System Overview.doc Last Saved On: 10/4/99 1:23 PM
Table 1-3
SFM Key Features
Description
Vaux5 LED– lit when AC power present in system.
Power supply connector, 24-pin
Door connector, 6-pin
Status LEDs
Switch pack
Fan control thermostat
Fan1 connector, 3-pin, connection to outboard system fan
Fan0 connector, 3-pin, connection to inboard system fan
Temperature sensor
PIC16C73 Microcontroller for RMC (Remote Management Console)
DP264 system board connector, 20-pin
Control panel connector, 10-pin
Unused, 10-pin
22V10 PAL chip
System Overview 1-11
