Installing the Pedestal 2-5

Installing the System

The system is shipped fully assembled. Perform each connection in Table 2-1
for installing your system. See Figure 2-4 for a view of the cable connections.
VGA
4
6
2
1
3
7
5
ENET
8
CAT0017
Figure 2-4. System Cable Connections
