Connecting a Single 6-Slot Subsystem

Part Number: ER-K8F6W-UA .A01 File Name: h-ch7 Using the Storage Subsystem.doc Last Saved On: 10/4/99 11:13 AM
Figure 7-11 displays the connections for a single 6-slot storage subsystem.
Perform the following procedure to connect the storage subsystem:
1. Connect the power source cable
other end to the power source.
2. Connect an end of the SCSI cable to one of the SCSI connectors on the
SCSI controller .
3. Connect the other end of the SCSI cable
storage backplane.
4. Terminate the connection at J7
1
J13
In
3
J10
J12
2
Figure 7-11. Connections for a Single 6-Slot Subsystem
Compaq Confidential – Need to Know Required
Writer: Robert Young Project: Compaq AlphaServer DS20E System Comments:
to J13 on the subsystem and the
to J10 (SCSI IN) on the
.
Backplane
4
J7
J11
CAT0147
