8-2 DS20E Reference Guide
Preparing to Install or Remove
Components
Part Number: ER-K8F6W-UA .A01 File Name: i-ch8 Installing Components.doc Last Saved On: 10/4/99 2:40 PM
To prepare your system for installation and removal of components, you will need to
assemble the required equipment and familiarize yourself with antistatic precautions.
You only need to remove the left side panel (top panel on a rackmount) to access the
user-replaceable internal components and controllers as shown in Figure 8-1.
2
Figure 8-1. Removing and Replacing the Side Panel on a Pedestal System
You need the following equipment to perform the installation and removal
procedures.
Phillips screwdriver
Antistatic wrist strap
Option board kit or device kit, if necessary
