Compaq AlphaServer DS20E Reference Manual page 106

4-22 DS20E Reference Guide
P00>>>b
(boot dkb0.0.0.3000.0 -file boot/vmlinux.gz -flags root=/dev/hda)
block 0 of dkb0.0.0.3000.0 is a valid boot block
reading 152 blocks from dkb0.0.0.3000.0
bootstrap code read in
base = 200000, image_start = 0, image_bytes = 13000
initializing HWRPB at 2000
initializing page table at 3ff8e000
initializing machine state
setting affinity to the primary CPU
jumping to bootstrap code
Linux version 2.2.12 (jestabro@linux04.mro.dec.com) (gcc version egcs-
2.90.29 980515 (egcs-1.0.3 release)) #21 Fri Sep 10 16:55:01 EDT 1999
Booting on Tsunami variation Clipper using machine vector Brick
Command line: root=/dev/hda bootdevice=scd0
setup_smp: 2 CPUs probed, cpu_present_map 0x3, boot_cpu_id 0
Console: colour VGA+ 80x25
Calibrating delay loop... 996.15 BogoMIPS
Memory: 1033720k available
POSIX conformance testing by UNIFIX
Entering SMP Mode.
secondary_console_message: on 0 from 1 HALT_REASON 0x0 FLAGS 0x1ee
secondary_console_message: on 0 message is 'P01>>>START
smp_boot_cpus: Total of 2 Processors activated (1992.29 BogoMIPS).
start_secondary: commencing CPU 1 current fffffc003ffe0000
Alpha PCI BIOS32 revision 0.04
PCI: Probing PCI hardware
Linux NET4.0 for Linux 2.2
. . .
General self-test: passed.
Serial sub-system self-test: passed.
Internal registers self-test: passed.
ROM checksum self-test: passed (0x24c9f043)
. . .
Red Hat Linux release 6.0 (Hedwig)
Kernel 2.2.12 on an alpha
peng1 login:
Part Number: FR-K8F6W-UA .A01 File Name: e-ch4 Operating the System.doc Last Saved On: 10/4/99 2:40 PM
booted_dev
booted_file
booted_osflags
3. Insert the boot floppy and enter the boot command. The following
example shows abbreviated boot output:
Compaq Confidential – Need to Know Required
Writer: Robert Young Project: Compaq AlphaServer DS20E System Comments:
bootfile=boot/vmlinux.gz
P01>>>'
