D-2 DS20E Reference Guide
Dimensions (HxWxD
Shipping Dimensions
Weight
When lifting:
Total added to cabinet
(brackets, slides, cables):
Shipping Weight
Clearance for Service
Dimensions (HxWxD)
Shipping Dimensions
Weight
Shipping Weight
Part Number: ER-K8F6W-UA .A01 File Name: p-appd System Specifications.doc Last Saved On: 10/4/99 11:26 AM
8.75 x 17.5 x 26 in / 22.2 x 44.5 x 66.0 cm (5U)
24 x 26.25 x 40 in / 61.0 x 66.0 x 101.6 cm
Nominal 80 lbs / 36 kg
Nominal 84 lbs / 38 kg
Nominal 100 lbs / 45 kg
Minimum 4 ft / 121.9 cm, 28 in / 71 cm withdrawal on rails
Rackmount Cabinet
H9A10 M-Series
67 x 23.6 x 43.27 in/
170 x 60 x 110 cm
73 x 36 x 48 in /
185.5 x 91.5 x 122 cm
Configuration dependent
Configuration dependent,
maximum payload 1,000 lbs
Compaq Confidential – Need to Know Required
Writer: Robert Young Project: Compaq AlphaServer DS20E System Comments:
Rackmount
Maximum 86 lbs / 39 kg
Maximum 88 lbs / 40 kg
Maximum 110 lbs / 50 kg
H9A15 M-Series
79 x 23.6 x 35.4 in
200 x 60 x 90 cm
85 x 36 x 48 in /
216 x 91.5 x 122 cm
1000 lbs / 450 kg
1056 lbs / 550 kg (normal)
1,408 lbs / 640 kg (maximum))
