3-26 DS20E Reference Guide

Dressing the Cables

Part Number: FR-K8F6W-UA .A01 File Name: d-ch3 Installing a Rack System.doc Last Saved On: 10/4/99 1:25 PM
Dress the cables through the cable clamps on the cable retractor assembly at
the rear of the system.
Figure 3-18. Dressing the Cables
1. Dress the cables through the cable clamps
cable retractor assembly.
2. Attach all cables to the member of the cable management arm that is
attached to the system.
CAUTION: Failure to attach the cables to the attached member of the
management arm may cause cables to become disconnected.
Compaq Confidential – Need to Know Required
Writer: Robert Young Project: Compaq AlphaServer DS20E System Comments:
PK1223
or tie wrap them to the
