Table 1-8 Rear Panel - Compaq AlphaServer DS20E Reference Manual

Table 1-8 lists all rear panel ports and connections for the system.
Figure
Legend
Five 64-bit PCI slots
One shared 64-bit
PCI /16-bit ISA slot
Parallel port
Serial port (COM2)
Keyboard port
Ethernet port
Mouse Port
Serial port (COM1)
AC Power inlet
SCSI breakouts
System fan 0
System fan 1
Universal Serial Bus
(USB)
Compaq Confidential – Need to Know Required
Writer: Robert Young Project: DS20E Reference Guide Comments:
Part Number: ER-K8F6W-UA .A01 File Name: b-ch1 System Overview.doc Last Saved On: 10/4/99 1:23 PM
Table 1-8
Rear Panel
Connector/Port
For option modules such as high performance network,
video, or disk controllers.
For option modules such as high performance network,
video, or disk controllers.
To parallel devices such as a printer.
Extra port to modem or any serial device.
To PS/2-compatible keyboard.
To network.
To PS/2-compatible mouse.
Standard port to modem or any serial device.
To power outlet.
For SCSI options.
System fan.
System fan.
Not supported at this time.
System Overview 1-25
Description
