Polycom RealPresence 1500 Administrator's Manual page 812

Manually Added, Modified, Deleted System Flags
Flag
MAX_TRACE_LEVEL
MAXIMUM_RECORDING_LINKS
MEDIA_NIC_MTU_SIZE
MIN_H239_HD1080_RATE
MINIMUM_FRAME_RATE_
THRESHOLD_FOR_SD
MIX_LINK_ENVIRONMENT
MS_CAC_AUDIO_MIN_BR
Polycom®, Inc.
Description
This flag indicates the debugging level for system support. The flag's values
have been modified for version 7.8 and is not backward compatible with
previous versions.
Possible values:
From version 7.8 - TRACE = t, DEBUG = d, INFO_NORMAL = n,
INFO_HIGH = i, WARN = w, ERROR = e, FATAL = f, OFF = o.
From version 7.7 or lower - TRACE = n/a, DEBUG = n/a, INFO_NORMAL =
n, INFO_HIGH = api, WARN = n/a, ERROR = crt, FATAL = n/a, OFF = no.
Default: n
The maximum number of Recording Links available for selection in the
Recording Links list and the Conference Profile - Recording dialog box.
Range: 1 - 100
Default: 20
MTU size (Maximum Transmission Unit controls the maximum data payload
size (bytes) transmitted in a single packet over the network.
The Collaboration Server sends large amount of data over the network and
may be required to adjust its MTU size according to the network
environment in which it is deployed.
MTU configuration is applicable to Collaboration Servers with RTM-LAN
cards installed only.
Default: 1500
Used to set the threshold line rate for HD Resolution Content : the line rate
at which the Collaboration Server will send Content at HD1080 Resolution.
Setting the flag to 0 disables HD Resolution Content.
Default: 768 kbps.
Low quality, low frame rate video is prevented from being sent to endpoints
by ensuring that an SD channel is not opened at frame rates below the
specified value.
Range: 0 -30
Default: 15
In H.239-enabled MIH Cascading, when MGC is on level 1, setting this flag
to YES will adjust the line rate of HD Video Switching conferences run on
the RealPresence Collaboration Server (RMX) 1500/1800/2000/4000 from
1920Kbps to 17897, 100bits/sec to match the actual rate of the HD Video
Switching conference running on the MGC.
Note: If the flag MIX_LINK_ENVIRONMENT is set to YES, the
IP_ENVIRONMENT_LINK flag must be set to NO.
The minimum bit rate for audio using the Microsoft CAC (Call Admission
Control) protocol. When the bit rate is lower than the
MS_CAC_AUDIO_MIN_BR, the call is not connected.
Range: 0 - 384
Default: 30
System Configuration Flags
782
