2 In the Network Services list pane right-click the IP Network Service to be set as the default, and
then click Set As H.323 Default, or Set As SIP Default.
The next time you access this menu, a check mark is added next to the network service type to
indicate its selection as default.
To set this IP Network Service for both H.323 and SIP connections, repeat step 2 and select the
option you need.
The following icons are used to indicate the default IP Network Service type:
Default IP Network Service Icons
Icon
Ethernet Settings
The Collaboration Server is set to automatically identify the speed and transmit/receive mode of each LAN
ports located on the RTM LAN or RTM ISDN cards that are added to the system. These port settings can
be manually configured if the specific switch requires it, via the Ethernet Settings dialog box. For more
details, see Ethernet Settings.
RealPresence Collaboration Server (RMX) 1500: The Port numbers displayed in the dialog box
do not reflect the physical Port numbers as labeled on the RealPresence Collaboration Server
(RMX) 1500 MCU.

Signaling Host IP Address and MCU Prefix in GK Indications

The Collaboration Server Web Client displays the Signaling Host IP Address and MCU Prefix in GK
parameters as defined in the Default H.323 Network Service.
Video/Voice Port Configuration and Resolution Configuration 1500/2000/4000
MPMx
These configurations are set for the system and are applied to all the Network Services.

Conference Profile

Registration of conferencing entities such as ongoing conferences, Meeting Rooms, Entry Queues, SIP
Factories and Gateway Sessions with SIP servers is done per conferencing entity. This allows better control
Polycom®, Inc.
Description
This Network Service supports both SIP and H.323 connections and is
designated as default for both SIP and H.323 connections.
This Network Service supports both SIP and H.323 connections and is
designated as default for H.323 connections.
This Network Service supports both SIP and H.323 connections and is
designated as default for SIP connections.
This Network Service supports only H.323 connections and is set as default for
H.323 connections.
This Network Service supports only SIP connections and is set as default for
SIP connections.
Network Security
538
