Resource Report - Collaboration Servers 1800 and 2000/4000 with MPMRx Cards

Port Usage Gauges

Collaboration Servers 1500 and 2000/4000 with MPMx media cards display port usage for Voice (Audio)
and Video separately.
Collaboration Servers 1800 and 2000/4000 with MPMRx media cards do not differentiate between Video
and Voice (Audio) resource usage and display a single port usage gauge.
The Port Gauge(s) show the total resource usage for the Collaboration Server and not per Network Service.
So it may not be an accurate representation of the availability of resources for conferencing, as one Network
Service may run out of available resources while another Network Service may have all of it resources
available. In such a case, the port gauge(s) may show that half of the system resources are available for
conferencing, while calls via the Network Service with no available resources will fail to connect.
Port Usage Gauges - Collaboration Servers 1500 and 2000/4000 with MPMx Cards
Port Usage Gauge - Collaboration Servers 2000/4000 with MPMRx Cards
Port Usage Gauge - Collaboration Server 1800 with MPMx Cards
