9A-33 Wiring Systems:
L: Floor harness
No./Color
L01/N Main harness (To E80)
L03/YEL Main harness (To E79)
L04/BLK Turn signal relay
L05/N J/B
L06/N J/B
L07/N Front door wire (Driver side) (To J01)
L08/N Instrument panel harness (To G07)
L09/BLU Instrument panel harness (To G08)
L10/N Front door switch (Driver side)
L11/YEL Side air-bag sensor (R)
L12/BLK Pretensioner (Driver side)
L13/N Rear door wire (R) (To J16)
L14/N Wheel speed sensor (RR)
L15/GRY Fuel pump wire (To R01)
L16/N Rear door switch (R)
L17/GRY Rear height sensor harness (To L66)
L18/BLK Side curtain air-bag (R)
L19/GRY Luggage compartment light
L20/N Rear combination lamp (R)
L21/BLK Diode #3
L22/N J/C
L23/N J/C
L25/YEL Side air-bag inflator (R)
L26/N Trailer
L27/N Instrument panel harness (To G72)
L28/N Instrument panel harness (To G73)
L: Rear height sensor wire
No./Color
L66/N Floor harness (To L17)
R: Fuel pump wire
No./Color
R01/GRY Floor harness (To L15)
R02/GRY Fuel pump and gauge
Connective position
Connective position
Connective position
No./Color
L29/YEL Instrument panel harness (To G55)
L30/YEL Side air-bag inflator (L)
L31/GRY Front door wire (Passenger side) (To J09)
L32/YEL (With
side A/B,
A/B SDM
Curtain A/B
system)
L33/YEL (With
side A/B,
A/B SDM
Curtain A/B
system)
L34/N Front door switch (Passenger side)
L35/YEL Side air- bag sensor (L)
L36/BLK Pretensioner (Passenger side)
L37/N Rear door wire (L) (To J21)
L38/GRY Wheel speed sensor (RL)
L40/N Rear door switch (L)
L41/BLK Side curtain air-bag (L)
L42/N Rear end door wire (To O01)
L43/N Rear combination lamp (L)
L44/N Keyless entry receiver
L45/BRN Inside antenna
L47/N ACC socket #1
L48/N ACC socket #1
L49/BRN Luggage antenna
L52/N Licence plate light #1
L53/N Licence plate light #2
L54/N Rear end door switch
L56/N Seat belt switch (Without seat heater)
Seat heater & Seat belt switch (Driver
L57/N
side)
L59/N Seat heater (Passenger side)
No./Color Connective position
L67/BLK Rear height sensor
No./Color Connective position
R03/N Fuel pump sub gauge
Connective position
