Headlight Washer Symptom Diagnosis (If Equipped)

Condition
Headlight washer
malfunction

Headlight Washer Operation Inspection

1) Turn ignition switch to ON position.
2) Turn lighting switch to "HEAD" position.
3) Make sure that washer fluid is spouted out from the headlight washer nozzle to the headlight surface when the
headlight washer switch or front washer switch is turned on.
If headlight washer does not operate, go to "Headlight Washer Symptom Diagnosis (If Equipped)".
NOTE
The headlight washer works only when the headlight is turned on. The headlight washer spouts
washer fluid on the headlight surface when the headlight washer switch or front washer switch is
turned on. In addition, in case using the front washer switch, the headlight washer works only once
after the headlight on.
Possible cause
Washer hose or nozzle clogged
Circuit fuse blown
Headlight washer switch faulty
Combination switch (washer switch)
faulty
Headlight washer pump faulty
Wiring or ground faulty
Headlight washer control module faulty Check headlight washer control module
Wipers / Washers:
Correction / Reference Item
Clean or repair clogged hose or nozzle.
Replace fuse and check for short circuit.
Check headlight washer switch referring to
"Headlight Washer Switch Inspection (If
Equipped): ".
Check washer switch referring to "Windshield
Wiper and Washer Switch Inspection: ".
Check headlight washer pump referring to
"Washer Pump Inspection: ".
Repair circuit.
referring to "Inspection of Headlight Washer
Control Module and Its Circuit: ".
9D-2
S5JB0A9404003
S5JB0A9404004
