To install the TP-260:
Unpack the TP-260 (see Unpacking).
1
Check the package contents (see
2
Install the TP-260 in your PC (see
3
Cable the TP-260 (see
4
When you have completed the above relevant sections you are then ready to start
configuring the gateway (See

Unpacking

To unpack the TP-260:
Open the carton and remove packing materials.
1
Remove the TP-260 board from the carton.
2
Check that there is no equipment damage.
3
Check, retain and process any documents.
4
Notify 3Com or your local supplier of any damage or discrepancies.
5
Retain any diskettes or CDs.
6

Package Contents

Ensure that in addition to the TP-260, the package contains:
For the 8 span version only, four E1/T1 cable splitters (shown in
CD (software and documentation).
This User Guide.
The V7122 Gateway Release Notes
Installing the TP-260
To install the TP-260 board:
End all applications running in the PC.
1
Shut down the PC, turn off the power, and remove the PC's cover.
2
Choose an available PCI slot and remove its blank rear bracket.
3
V7122 Gateway User Guide
Package Contents).

Installing the

Cabling the TP-260).
C hapter 4: Getting Started).
1
TP-260).
Figure 19).
