3Com V7122 User Manual page 175

ini File Field Name
Web Parameter Name
SIPDestinationPort
[SIP Destination Port]
EnableTCPConnectionReu
se
[Enable TCP Connection
Reuse]
LocalSIPPort
[SIP Local Port]
SIPGatewayName
[Gateway Name]
IsProxyUsed
[Enable Proxy]
V7122 Gateway User Guide
Valid Range and Description
SIP destination port for sending initial SIP requests.
The valid range is 1 to 65534. The default port is 5060.
SIP responses are sent to the port specified in the Via header.
Enables the reuse of the same TCP connection for all calls to the same
destination.
Valid options include:
0 = Use a separate TCP connection for each call (default)
1 = Use the same TCP connection for all calls
Local UDP port used to receive SIP messages.
The valid range is 1 to 65534. The default port is 5060.
Use this parameter to assign a name to the gateway (for example,
'gateway1.com'). Ensure that the name you choose is the one that the
Proxy is configured with to identify your media gateway.
If specified, the gateway Name is used as the host part of the
SIP URI, in the From header. If not specified, the gateway IP
address is used instead (default).
0 = Proxy isn't used, the internal routing table is used instead (default).
1 = Proxy is used.
175
