C 15: SNMP-B
HAPTER
M
ANAGEMENT
Simple Network Management Protocol (SNMP) is a standards-based network control
protocol for managing elements in a network. The SNMP Manager (usually implemented by
a Network Management System (NMS) or an Element Management System (EMS))
connects to an SNMP Agent (embedded on a remote Network Element (NE)) to perform
network element Operation, Administration and Maintenance (OAM).
Both the SNMP Manager and the NE see the same database to retrieve information or
configure parameters. This database is referred to as the Management Information Base
(MIB), and is a set of statistical and control values. Apart from the standard MIBs
documented in IETF RFCs, SNMP additionally enables the use of private MIBs, containing a
non-standard information set (specific functionality provided by the NE).
Directives, issued by the SNMP Manager to an SNMP Agent, consist of the identifiers of
SNMP variables (referred to as MIB object identifiers or MIB variables) along with
instructions to either get the value for that identifier, or set the identifier to a new value
(configuration). The SNMP Agent can also send unsolicited events towards the EMS, called
SNMP traps.
The definitions of MIB variables supported by a particular agent are incorporated in
descriptor files, written in Abstract Syntax Notation (ASN.1) format, made available to EMS
client programs so that they can become aware of MIB variables and their use.
The device contains an embedded SNMP Agent supporting both general network MIBs
(such as the IP MIB), VoP-specific MIBs (such as RTP) and our proprietary MIBs (acBoard,
acGateway, acAlarm and other MIBs), enabling a deeper probe into the inter-working of the
device. All supported MIB files are supplied to customers as part of the release.

SNMP Standards and Objects

SNMP Message Standard

Four types of SNMP messages are defined:
Get: A request that returns the value of a named object.
Get-Next: A request that returns the next name (and value) of the 'next' object supported
by a network device given a valid SNMP name.
Set: A request that sets a named object to a specific value.
