Radius Parameters - 3Com V7122 User Manual

RADIUS Parameters

For detailed information on the supported RADIUS attributes, see
Attributes.
RADIUS Parameter
Table 39
ini File Field Name
Web Parameter Name
EnableRADIUS
[Enable RADIUS]
AAAIndications
[AAA Indications]
MaxRADIUSSessions
[Max. RADIUS Sessions]
SharedSecret
[Shared Secret]
RADIUSRetransmission
[RADIUS Max.
Retransmissions]
RadiusTO
RADIUSAuthServerIP
[RADIUS Authentication
Server IP Address]
RADIUSAuthPort
[RADIUS Authentication Port]
RADIUSAccServerIP
[RADIUS Accounting Server
IP Address]
RADIUSAccPort
[RADIUS Accounting Port]
RadiusAccountingType
[RADIUS Accounting Type]
DefaultAccessLevel
[Default Access Level]
V7122 Gateway User Guide
Valid Range and Description
0 = RADIUS application is disabled (default).
1 = RADIUS application is enabled.
0 = No indications (default).
3 = Accounting only
Number of concurrent calls that can communicate with the RADIUS server
(optional).
The valid range is 0 to 240.
The default value is 240.
'Secret' used to authenticate the gateway to the RADIUS server. It should be
a cryptographically strong password.
Number of retransmission retries.
The valid range is 1 to 10.
The default value is 3.
The interval between each retry (measured in seconds).
The valid range is 1 to 30.
The default value is 10.
IP address of Authentication and Authorization server.
Port number of Authentication and Authorization server.
The default value is 1645.
IP address of accounting server.
Port number of Radius accounting server.
The default value is 1646.
Determines when a RADIUS accounting report is issued.
0 = At the Release of the call only (default).
1 = At the Connect and Release of the call.
2 = At the Setup and Release of the call.
Defines the default access level for the gateway when the RADIUS
(authentication) response doesn't include an access level attribute.
The valid range is 0 to 255. The default value is 200 (Security Administrator').
Supported RADIUS
171
