Snmp Parameters - 3Com V7122 User Manual

ini File Field Name
Web Parameter Name
BehaviorUponRadiusTimeo
ut
[Device Behavior Upon
RADIUS Timeout]
RadiusLocalCacheMode
[Local RADIUS Password
Cache Mode]
RadiusLocalCacheTimeout
[Local RADIUS Password
Cache Timeout]
RadiusVSAVendorID
[RADIUS VSA Vendor ID]
RadiusVSAAccessAttribute
[RADIUS VSA Access Level
Attribute]

SNMP Parameters

SNMP Parameters
Table 40
ini File Field Name
Web Parameter Name
DisableSNMP
[Enable SNMP]
SNMPPort
SNMPTrustedMGR_x
172
Valid Range and Description
Defines the gateway's operation if a response isn't received from the RADIUS
server after the 5 seconds timeout expires:
0 (Deny Access) = the gateway denies access to the Web and Telnet
embedded servers.
1 (Verify Access Locally) = the gateway checks the local username and
password (default).
Defines the gateway's mode of operation regarding the timer (configured by
the parameter RadiusLocalCacheTimeout) that determines the validity of the
username and password (verified by the RADIUS server).
0 (Absolute Expiry Timer) = when you access a Web screen, the timeout
doesn't reset but rather continues decreasing.
1 (Reset Timer Upon Access) = upon each access to a Web screen, the
timeout always resets (reverts to the initial value configured by
RadiusLocalCacheTimeout).
Defines the time (in seconds) the locally stored username and password
(verified by the RADIUS server) are valid. When this time expires, the
username and password becomes invalid and a must re-verified with the
RADIUS server.
The valid range is 1 to 0xFFFFFF. -1 = Never expires. 0 = Each request
requires RADIUS authentication.
The default value is 300 (5 minutes).
Defines the vendor ID the gateway accepts when parsing a RADIUS response
packet.
The valid range is 0 to 0xFFFFFFFF. The default value is 5003.
Defines the code that indicates the access level attribute in the Vendor
Specific Attributes (VSA) section of the received RADIUS packet.
The valid range is 0 to 255. The default value is 35.
Valid Range and Description
0 = SNMP is enabled (default).
1 = SNMP is disabled and no traps are sent.
The device's local UDP port used for SNMP Get/Set commands.
The range is 100 to 3999.
The default port is 161.
Up to five IP addresses of remote trusted SNMP managers from which
the SNMP agent accepts and processes get and set requests.
If no values are assigned to these parameters any
manager can access the device.
Trusted managers can work with all community strings.
V7122 GatewayUser Guide
