ini File Field Name
Web Parameter Name
Internal Firewall Parameters
AccessList_Source_IP
[Source IP]
AccessList_Net_Mask
[Mask]
AccessList_Start_Port
AccessList_End_Port
[Local Port Range]
AccessList_Protocol
[Protocol]
AccessList_Packet_Size
[Packet Size]
AccessList_Byte_Rate
[Byte Rate]
AccessList_Byte_Burst
[Burst Bytes]
AccessList_Allow_Type
[Action Upon Match]
AccessList_MatchCount
[Match Count]
170
Valid Range and Description
IP address (or DNS name) of source network, or a specific host.
IP network mask. 255.255.255.255 for a single host or the appropriate value
for the source IP addresses.
The IP address of the sender of the incoming packet is bitwise ANDed with
this mask and then compared to the field 'Source IP'.
The destination UDP/TCP ports (on this device) to which packets are sent.
The valid range is 0 to 65535.
When the protocol type isn't TCP or UDP, the entire range must be
provided.
The protocol type (for example, UDP, TCP, ICMP, ESP or 'Any'), or the IANA
protocol number (in the range of 0 (Any) to 255).
The protocol field also accepts the abbreviated strings 'SIP',
'MGCP', 'MEGACO' and 'HTTP'. Specifying these strings implies
selection of the TCP or UDP protocols, and the appropriate port
numbers as defined on the device.
Maximum allowed packet size.
The valid range is 0 to 65535.
When filtering fragmented IP packets, the Packet Size field relates
to the overall (reassembled) packet size, not to the size of each
fragment.
Expected traffic rate (bytes per second).
Tolerance of traffic rate limit (number of bytes)
Action upon match (allow or block)
A read-only field that provides the number of packets accepted / rejected by a
specific rule.
