Column Name
[ini File Parameter Name]
Network Type

Configuring the Media Settings

Use these menus to set the gateway's channel parameters. These parameters are applied to
all the gateway's channels. Several Channels Settings parameters can be configured per call
using profiles (see Release Cause
on-the-fly. Changes take effect from the next call.
From the Media Settings you can:
Define the Voice Settings.
Define the Fax / Modem and CID Settings.
Define the RTP / RTCP Settings.
Define the IPmedia Settings.
Define General Media Settings.
The parameters 'MF Transport Type' (Voice Settings screen) and the five Answer
Detector (IPmedia Settings screen) parameters are not applicable to the gateway.
The parameters 'Fax Transport Mode' (Fax / Modem / CID Settings screen) is
overridden by the parameter 'IsFaxUsed'.

Configuring the Trunk Settings

To configure the Trunk Settings:
Open the 'Trunk Settings' screen (Advanced Configuration menu > Trunk Settings);
1
the 'Trunk Settings' screen is displayed.
Initially, the screen appears with the parameters fields grayed (indicating read-only). The
Stop Trunk button appears at the bottom of the screen.
The Trunk Status indicators appear colored.
their descriptions.
V7122 Gateway User Guide
Description
Specifies the network type the routing rule is applied to.
OAM (default).
Control.
Media.
For detailed information on the network types, see
Mapping). Note that channel parameters are changeable
Table 29
Multiple IPs.
shows the possible indicators and
105
