To add the pre-recorded voice files to the 'Voice Prompts' screen follow one of these
3
procedures:
Select the files and drag them to the 'Voice Prompts' screen.
Click the Add File(s) button; the 'Select Files' screen opens. Select the required
Voice Prompt files and click the Add>> button. Close the 'Select Files' screen.
Arrange the files according to your requirements by dragging and dropping them from
4
one location in the list to another. Note that the sequence of the files determines their
assigned Voice Prompt ID.
Use the Play button to play wav files through your PC speakers.
Use the Remove and Remove all buttons to delete files from the list.
For each of the raw files, select a coder that corresponds with the coder it was originally
5
recorded in by completing the following steps:
Double-click or right-click the required file(s); the 'File Data' window (shown in
Figure 131) appears.
From the 'Coder' drop-down list, select the required coder type.
In the 'Description' field, enter additional identifying information.
Close the 'File Data' window.
For wav files, a coder is automatically selected from the wav file's header.
Figure 131 File Data Window
In the 'Output' field, specify the output directory in which the Voice Prompts file is
6
generated followed by the name of the Voice Prompts file (the default name is
voiceprompts.dat).
Click the Make File(s) button; the Voice Prompts loadable file is produced.
7

Creating a loadable CAS Protocol Table File

To create a loadable CAS protocol table file follow the next 11 steps:
Construct the CAS protocol files (xxx.txt and UserProt_defines_xxx.h).
1
Copy the files generated in the previous step to the same directory the TrunkPack
2
Downloadable Conversion utility is located and ensure that the files CASSetup.h and
cpp.exe are also located in the same directory.
