Getting Acquainted with the Web Interface

Figure 22 shows the general layout of the Web Interface screen.
V7122 Web Interface
Figure 22
The Web Interface screen features the following components:
Title bar: contains three configurable elements: corporate logo, a background image and
the product's name. For information on how to modify these elements, see
the V7122 Web Interface.
Product name: the gateway's module name (Module 1 or Module 2).
Main menu bar: always appears on the left of every screen to quickly access
parameters, submenus, submenu options, functions and operations.
Submenu bar: appears on the top of screens and contains submenu options.
Main action frame: the main area of the screen in which information is viewed and
configured.
Home icon: when clicked it opens the 'Trunk & Channel Status' screen (refer to
Monitoring the Gateway's Trunks &
Corporate logo: 3Com corporate logo. For information on how to remove this logo, see
Customizing the V7122 Web
