Ethernet Port Information Screen
Figure 64
Ethernet Port Information Parameters
Table 33
Parameter Description
Active Port Shows the active Ethernet port (1 or 2).
Port 1 Duplex Mode Shows the Duplex mode Ethernet port 1 is using (Half Duplex or Full Duplex).
Port 1 Speed Shows the speed, in Mbps, that Ethernet port 1 is using (10 or 100 Mbps).
Port 2 Duplex Mode Shows the Duplex mode Ethernet port 2 is using (Half Duplex or Full Duplex).
Port 2 Speed Shows the speed, in Mbps, that Ethernet port 2 is using (10 or 100 Mbps).

Software Update Menu

The 'Software Update' menu enables users to upgrade the gateway software by loading a
new cmp file along with the ini and a suite of auxiliary files, or to update the existing auxiliary
files.
The 'Software Update' menu comprises two submenus:
Software Upgrade Wizard (see
Auxiliary Files (see
When upgrading the gateway's software you must load the new cmp file with all
other related configuration files.

Software Upgrade Wizard

The Software Upgrade Wizard guides users through the process of software upgrade:
selecting files and loading them to the gateway. The wizard also enables users to upgrade
software while maintaining the existing configuration. Using the wizard obligates users to
load and burn a cmp file. Users can choose to also use the wizard to load the ini and
auxiliary files (for example, Call Progress Tones) but this option cannot be pursued without
loading the cmp file. For the ini and each auxiliary file type, users can choose to reload an
existing file, load a new file or not load a file at all.
The Software Upgrade Wizard allows you to load the following files:
132
Software Upgrade
Auxiliary Files).
Wizard).
