3Com V7122 User Manual page 153

ini File Field Name
Web Parameter Name
EnableSyslog
[Enable Syslog]
BaseUDPport
[RTP Base UDP Port]
RemoteBaseUDPPort
[Remote RTP Base UDP Port]
V7122 Gateway User Guide
Valid Range and Description
Sends the logs and error message generated by the gateway
to the Syslog Server.
0 = Disable (logs and errors are not sent to the Syslog Server
-- default).
1 = Enable
If you enable Syslog (that is, EnableSyslog = 1),
you must enter an IP address and a port number
using SyslogServerIP and SyslogServerPort
parameters.
Syslog messages may increase the network
traffic.
To configure the Syslog logging levels use the
parameter 'GwDebugLevel'.
Lower boundary of UDP port used for RTP, RTCP (Real-
Time Control Protocol) (RTP port + 1) and T.38 (RTP port +
2). The upper boundary is the Base UDP Port + 10 * (number
of gateway's channels).
The range of possible UDP ports is 6,000 to 64,000.
The default base UDP port is 6000.
For example:
If the Base UDP Port is set to 6000 (the default) then:
The first channel uses the following ports: RTP 6000, RTCP
6001 and T.38 6002;
the second channel uses: RTP 6010, RTCP 6011 and T.38
6012, and the like.
If RTP Base UDP Port is not a factor of 10, the
following message is generated: 'invalid local RTP
port'.
For detailed information on the default
RTP/RTCP/T.38 port allocation, see
RTP/RTCP/T.38 Port
Determines the lower boundary of UDP ports used for RTP,
RTCP and T.38 by a remote gateway. If this parameter is set
to a non-zero value, ThroughPacket™ is enabled. Note that
the value of 'RemoteBaseUDPPort' on the local gateway
must equal the value of 'BaseUDPPort' of the remote
gateway. The gateway uses these parameters to identify and
distribute the payloads from the received multiplexed IP
packet to the relevant channels.
The valid range is the range of possible UDP ports: 6,000 to
64,000.
The default value is 0 (ThroughPacket™ is disabled).
To enable ThroughPacket™ the parameters
'L1L1ComplexTxUDPPort' and
'L1L1ComplexRxUDPPort' must be set to a non-zero
value.
For detailed information on ThroughPacket™, see
ThroughPacket™.
Default
Allocation.
153
