Accessing the CLI
To access the CLI using the Embedded Telnet Server:
Enable the Embedded Telnet Server:
1
a) Access the gateway's Embedded Web Server (see
Server).
b) Set the parameter 'Embedded Telnet Server' (under Advanced Configuration >
Network Settings > Application Settings) to 'Enable (Unsecured)' or 'Enable Secured
(SSL)'.
c) Click the Maintenance button on the main menu bar; the Maintenance Actions
screen is displayed.
d) From the 'Burn to FLASH' drop-down list, select 'Yes', and then click the Reset
button; the device is shut down and re-activated. A message about the waiting period is
displayed. The screen is refreshed.
Use a standard Telnet application to connect to the gateway 's Embedded Telnet Server.
2
Note that if the Telnet server is set to SSL mode, a special Telnet client is required on
your PC to connect to the Telnet interface over a secured connection.
Login using the username ('Admin') and password ('Admin').
3
To access the CLI using the RS-232 port:
Connect the RS-232 port to your PC (For the V7122, see
1
Your PC.
Use serial communication software (for example, HyperTerminal
2
gateway.
Set your serial communication software to the following communications port settings:
Baud Rate:
Data bits:
Parity:
Stop bits:
Flow control:
The CLI prompt becomes available.
Assign an IP Address
To assign an IP address using the CLI:
At the prompt type
1
62
115,200 bps
8
None
1
None
and then press Enter; the configuration folder is accessed.
conf
Accessing the Embedded Web
Connecting the RS-232 Port to
TM
) to connect to the
