3Com V7122 User Manual page 159

ini File Field Name
Web Parameter Name
NFSServers_GID
[GID]
NFSServers_VlanType
[VLAN Type]
Internal Firewall
AccessList_Source_IP
[Source IP]
AccessList_Net_Mask
[Mask]
AccessList_Start_Port
AccessList_End_Port
[Local Port Range]
AccessList_Protocol
[Protocol]
AccessList_Packet_Size
[Packet Size]
AccessList_Byte_Rate
[Byte Rate]
AccessList_Byte_Burst
Burst Bytes
AccessList_Allow_Type
[Action Upon Match]
AccessList_MatchCount
[Match Count]
V7122 Gateway User Guide
Valid Range and Description
Group ID used in authentication if using AUTH_UNIX.
The valid range is 0 to 65537. The default is 1
The VLAN, OAM [0] or Media [1], to use when accessing the
remote file system. The default is to use the media VLAN.
This parameter applies only if VLANs are enabled or if
Multiple IPs is configured (see
IP address (or DNS name) of source network, or a specific
host.
IP network mask. 255.255.255.255 for a single host or the
appropriate value for the source IP addresses.
The IP address of the sender of the incoming packet is
bitwise ANDed with this mask and then compared to the field
'Source IP'.
The destination UDP/TCP ports (on this device) to which
packets are sent.
The valid range is 0 to 65535.
When the protocol type isn't TCP or UDP, the entire
range must be provided.
The protocol type (for example, UDP, TCP, ICMP, ESP or
'Any'), or the IANA protocol number (in the range of 0 (Any)
to 255).
The protocol field also accepts the abbreviated
strings 'SIP', 'MGCP', 'MEGACO' and 'HTTP'.
Specifying these strings implies selection of the TCP
or UDP protocols, and the appropriate port numbers
as defined on the device.
Maximum allowed packet size.
The valid range is 0 to 65535.
When filtering fragmented IP packets, the Packet
Size field relates to the overall (reassembled) packet
size, not to the size of each fragment.
Expected traffic rate (bytes per second).
Tolerance of traffic rate limit (number of bytes)
Action upon match (allow or block)
A read-only field that provides the number of packets
accepted / rejected by a specific rule.
VLANS and Multiple IPs).
