To configure the SNMP Managers Table:
Access the 'Management Settings' screen (Advanced Configuration menu >
1
Management Settings); the 'Management Settings' screen is displayed.
Open the SNMP Managers Table screen by clicking the arrow sign (-->) to the right of
2
the SNMP Managers Table label; the SNMP Managers Table screen is displayed
(Figure 53).
Configure the SNMP manager's parameters.
3
Click the Submit button to save your changes.
4
To save the changes so they are available after a power fail, see
5
SNMP Managers Table Screen
Figure 53
If you clear a checkbox and click Submit, all settings in the same row revert to their
defaults.
Configuring the SNMP Community Strings
Use the SNMP Community Strings table to configure up to five read-only and up to five read
/ write SNMP community strings, and to configure the community string that is used for
sending traps. For detailed information on SNMP community strings, see
Names.
To configure the SNMP Community Strings:
Access the 'Management Settings' screen (Advanced Configuration menu >
1
Management Settings); the 'Management Settings' screen is displayed.
Open the SNMP Community Strings screen by clicking the arrow sign (-->) to the right of
2
the SNMP Community Strings label; the SNMP Community Strings screen is displayed
(Figure 54).
Configure the SNMP Community Strings parameters according to
3
Click the Submit button to save your changes.
4
To save the changes so they are available after a power fail, see
5
V7122 Gateway User Guide
Saving Configuration.
SNMP Community
Table 40.
Saving Configuration.
121
