Figure 105 Example of an SPD Table
[ IPSEC_SPD_TABLE ]
Format SPD_INDEX = IPSecPolicyRemoteIPAddress, IpsecPolicySrcPort,
IPSecPolicyDStPort,IPSecPolicyProtocol, IPSecPolicyLifeInSec,
IPSecPolicyProposalEncryption_0, IPSecPolicyProposalAuthentication_0,
IPSecPolicyProposalEncryption_1, IPSecPolicyProposalAuthentication_1,
IPSecPolicyKeyExchangeMethodIndex, IPSecPolicyLocalIPAddressType;
IPSEC_SPD_TABLE 0 = 10.11.2.21, 0, 0, 17, 900, 1,2, 2,2 ,1, 0;
[ \IPSEC_SPD_TABLE ]
In the SPD example above, all packets designated to IP address 10.11.2.21 that originates
from the OAM interface (regardless to their destination and source ports) and whose protocol
is UDP are encrypted, the SPD also defines an SA lifetime of 900 seconds and two security
proposals: DES/SHA1 and 3DES/SHA1.
To configure the SPD table using the Embedded Web Server follow the next 6 steps:
Access the Embedded Web Server (see
1
Open the 'IPSec Table' screen (Advanced Configuration menu > Security Settings >
2
IPSec Table option); the 'IPSec Table' screen is displayed.
342
Accessing the Embedded Web
V7122 GatewayUser Guide
Server).
