ini File Parameter Name
SS7_LINKSET_ACTION
SS7_SN_ACTION_RESULT

SS7 MTP2 Tunneling ini File Example

For the SS7 MTP2 tunneling ini file example, note the following:
The first ini file acts as an MTP2 tunneling central side (M2UA MGC links).
There are eight SS7 links - four links of type: MTP2 MGC, and four links of type MTP2.
Each pair of links (one MTP2 MGC and one MTP2) defines an MTP2 tunnel.
There is one interface that is used for the M2UA MGC <=> M2UA SG (Signaling
Gateway) connection.
There are four interface IDs defined: one per link (M2UA MGC side).
This file is intended for ITU link variant (E1 trunks).
To load the example SS7 MTP2 tunneling ini files to V7122 gateways:
Load the ini file that is shown in
1
Load the ini file that is shown in
MGC gateway connects (over IP) to the SG gateway. For information on loading an ini
file to the gateway, see
In the MGC gateway, change the parameter 'SS7_DEST_IP' to the actual IP address of
2
the M2UA SG gateway.
Change the value of the 'SyslogServerIP' parameter in the MGC and SG gateways to
3
your Syslog server IP address.
Figure 101 SS7 MTP2 Tunneling ini File Example – MGC
[TDM BUS configuration]
; 1=aLaw 3=ulaw
PCMLawSelect=
;1 - internal, 3 - mvip, 4 - Network, 8 - h110a, 9 - h110b, 10 - Netref
TDMBusClockSource= 1
[Trunk Configuration]
;e1_euro_isdn=1 t1_isdn=2 ;e1_cas_r2=8 (8 for fcd); e1_trans_62=5
ProtocolType = 5
TraceLevel = 0
; acCLOCK_MASTER_ON =1
CLOCKMASTER= 1
;acUSER_TERMINATION_SIDE = 0
328
Description
Determines the management field for actions.
0 = acSS7LINKSET_PS_ACTION_NONE (default)
1 = acSS7LINKSET_PS_ACTION_OFFLINE
2 = acSS7LINKSET_PS_ACTION_INSERVICE
3 = acSS7LINKSET_PS_ACTION_ACTIVATE
4 = acSS7LINKSET_PS_ACTION_DEACTIVATE
Determines the management field for actions result.
The valid range is
acPARAMSET_ACTION_RESULT_SUCCEEDED to
acPARAMSET_ACTION_RESULT_FAILED. The default value is
acPARAMSET_ACTION_RESULT_SUCCEEDED.
Figure 101
Figure 102
Modifying an ini File.
1
to a tunnel central gateway (MTP2 MGC).
to a tunnel remote gateway (MTP2 SG); the
