ini File Field Name
Web Parameter Name
SourceNumberMapIP2Tel
[Source Phone Number
Manipulation Table for
IP Tel calls]
For ETSI ISDN variant, the following Number Plan and Type combinations (Plan/Type) are supported in
the Destination and Source Manipulation tables:
0,0 = Unknown, Unknown
9,0 = Private, Unknown
9,1 = Private, Level 2 Regional
9,2 = Private, Level 1 Regional
9,3 = Private, PISN Specific
9,4 = Private, Level 0 Regional (local)
1,0 = Public(ISDN/E.164), Unknown
1,1 = Public(ISDN/E.164), International
1,2 = Public(ISDN/E.164), National
1,3 = Public(ISDN/E.164), Network Specific
1,4 = Public(ISDN/E.164), Subscriber
1,6 = Public(ISDN/E.164), Abbreviated
For NI-2 and DMS-100 ISDN variants the valid combinations of TON and NPI for calling and called
numbers are (Plan/Type):
0/0 - Unknown/Unknown
1/1 - International number in ISDN/Telephony numbering plan
1/2 - National number in ISDN/Telephony numbering plan
1/4 - Subscriber (local) number in ISDN/Telephony numbering plan
9/4 - Subscriber (local) number in Private numbering plan
220
Valid Range and Description
Manipulate the source number for IP to Tel calls.
SourceNumberMapIP2Tel = a,b,c,d,e,f,g,h,i
a = Source number prefix
b = Number of stripped digits from the left, or (if brackets are used)
from the right. A combination of both options is allowed.
c = String to add as prefix, or (if brackets are used) as suffix. A
combination of both options is allowed.
d = Number of remaining digits from the right
e = Q.931 Number Plan
f = Q.931 Number Type
g = Destination number prefix
h =Calling number presentation (0 to allow presentation, 1 to restrict
presentation)
I = Source IP address (obtained from the Request-URI in the INVITE
message).
The 'b' to 'f' and 'h' manipulation rules are applied if the called and calling
numbers match the 'a', 'g' and 'I' conditions.
The manipulation rules are executed in the following order: 'b', 'd' and 'c'.
Parameters can be skipped by using the sign '$$', for example:
SourceNumberMapIP2Tel =01,2,972,$$,0,$$,034,1
SourceNumberMapIP2Tel =03,(2),667,$$,$$,0,22
The Source IP address can include the 'x' wildcard to represent
single digits. For example: 10.8.8.xx represents all the
addresses between 10.8.8.10 to 10.8.8.99. The '*' wildcard
represents any number between 0 and 255, for example,
10.8.8.* represents all the addresses between 10.8.8.0 and
10.8.8.255.
