ini File Field Name
Web Parameter Name
SMDI
[Enable SMDI]
SMDITimeOut
[SMDI Timeout]
LineTransferMode
[Line Transfer Mode]
WaitForDialTime
[Wait For Dial Time]
MWIOnCode
[MWI On Digit Pattern]
MWIOffCode
[MWI Off Digit Pattern]
TelDisconnectCode
[Disconnect Call Digit
Pattern]
The following digit pattern parameters apply only to VM applications that use the DTMF communication
method. For the available patterns' syntaxes, see the User Guide.
DigitPatternForwardOnB
usy
[Forward on Busy Digit
Pattern]
DigitPatternForwardOnN
oAnswer
[Forward on No Answer
Digit Pattern]
DigitPatternForwardOnD
ND
[Forward on Do Not
Disturb Digit Pattern]
202
Valid Range and Description
Enables the Simplified Message Desk Interface (SMDI) on the gateway.
0 = Normal serial (default).
1 = Enable RS-232 SMDI interface.
When the RS-232 connection is used for SMDI messages (Serial
SMDI) it cannot be used for other applications, for example, to
access the Command Line Interface.
Determines the time (in msec) that the gateway waits for an SMDI Call Status
message before or after a Setup message is received. This parameter is used
to synchronize the SMDI and CAS interfaces.
If the timeout expires and only an SMDI message was received, the SMDI
message is dropped. If the timeout expires and only a Setup message was
received, the call is established.
The valid range is 0 to 10000 (10 seconds). The default value is 2000.
Determines the transfer method used by the gateway.
0 = IP (default).
1 = PBX blind transfer.
Determines the delay after hook-flash is generated and dialing is begun.
Applies to call transfer (TrunkTransferMode = 3) on CAS gateways.
The valid range (in milliseconds) is 0 to 20000 (20 seconds). The default value
is 1000 (1 second).
Determines a digit code used by the gateway to notify the PBX of messages
waiting for a specific extension. This code is added as prefix to the dialed
number.
The valid range is a 25-character string.
Determines a digit code used by the gateway to notify the PBX that there
aren't any messages waiting for a specific extension. This code is added as
prefix to the dialed number.
The valid range is a 25-character string.
Determines a digit pattern that, when received from the Tel side, indicates the
gateway to disconnect the call.
The valid range is a 25-character string.
Determines the digit pattern used by the PBX to indicate 'call forward on busy'.
The valid range is a 120-character string.
Determines the digit pattern used by the PBX to indicate 'call forward on no
answer'.
The valid range is a 120-character string.
Determines the digit pattern used by the PBX to indicate 'call forward on do
not disturb'.
The valid range is a 120-character string.
