ini File Field Name
Web Parameter Name
NumberMapIP2Tel
[Destination Phone Number
Manipulation Table for
IP Tel calls]
SourceNumberMapTel2IP
[Source Phone Number
Manipulation Table for
Tel IP calls]
V7122 Gateway User Guide
Valid Range and Description
Manipulate the destination number for IP to Tel calls.
NumberMapIP2Tel = a,b,c,d,e,f,g,h,i
a = Destination number prefix
b = Number of stripped digits from the left, or (if brackets are used)
from the right. A combination of both options is allowed.
c = String to add as prefix, or (if brackets are used) as suffix. A
combination of both options is allowed.
d = Number of remaining digits from the right
e = Q.931 Number Plan
f = Q.931 Number Type
g = Source number prefix
h = Not applicable, set to $$
i = Source IP address (obtained from the Contact header in the
INVITE message)
The 'b' to 'f' manipulation rules are applied if the called and calling numbers
match the 'a', 'g' and 'i' conditions.
The manipulation rules are executed in the following order: 'b', 'd' and 'c'.
Parameters can be skipped by using the sign '$$', for example:
NumberMapIP2Tel =01,2,972,$$,0,$$,034
NumberMapIP2Tel =03,(2),667,$$,$$,0,22,$$,10.13.77.8
The Source IP address can include the 'x' wildcard to represent
single digits. For example: 10.8.8.xx represents all the
addresses between 10.8.8.10 to 10.8.8.99. The '*' wildcard
represents any number between 0 and 255, for example
10.8.8.* represents all the addresses between 10.8.8.0 and
10.8.8.255.
SourceNumberMapTel2IP = a,b,c,d,e,f,g,h
a = Source number prefix
b = Number of stripped digits from the left, or (if in brackets are used)
from right. A combination of both options is allowed.
c = String to add as prefix, or (if in brackets are used) as suffix. A
combination of both options is allowed.
d = Number of remaining digits from the right
e = Number Plan used in RPID header
f = Number Type used in RPID header
g =Destination number prefix
h =Calling number presentation (0 to allow presentation, 1 to restrict
presentation)
The 'b' to 'f' and 'h' manipulation rules are applied if the called and calling
numbers match the 'a' and 'g' conditions.
The manipulation rules are executed in the following order: 'b', 'd' and 'c'.
Parameters can be skipped by using the sign '$$', for example:
SourceNumberMapTel2IP=01,2,972,$$,0,0,$$,1
SourceNumberMapTel2IP=03,(2),667,$$,0,0,22,0
