Since the four action buttons (Cancel, Reset, Back, and Next) are now activated
5
(following cmp file loading).
You can now choose to either:
a) Click Reset; the gateway resets, utilizing the new cmp you loaded and utilizing the
current configuration files.
b) Click Cancel; the gateway resets utilizing the cmp, ini and all other configuration files
that were previously stored in flash memory. Note that these are NOT the files you
loaded in the previous Wizard steps.
c) Click Back; the 'Load a cmp File' screen is reverted to; see
d) Click Next; the 'Load an ini File' screen opens; see
or any other auxiliary file listed in the Wizard is optional.
As you progress, the file type list on the left indicates which file type loading is in
process by illuminating green (until 'FINISH').
Load an ini File Screen
Figure 68
In the 'Load an ini File' screen, you can now choose to either:
6
a) Click Browse and navigate to the ini file; the check box 'Use existing configuration',
by default checked, becomes unchecked. Click Send File; the ini file is loaded to the
gateway and you're notified as to a successful loading.
b) Ignore the Browse button (its field remains undefined and the check box 'Use
existing configuration' remains checked by default).
c) Ignore the Browse button and uncheck the 'Use existing configuration' check box; no
ini file is loaded, the gateway uses its factory-preconfigured values.
You can now choose to either:
7
a) Click Cancel; the gateway resets utilizing the cmp, ini and all other configuration files
that were previously stored in flash memory. Note that these are NOT the files you
loaded in the previous Wizard steps.
V7122 Gateway User Guide
Figure 66.
Figure 68. Loading a new ini file
