Number Manipulation and Routing Parameters

Number Manipulation and Routing Parameters
Table 44
ini File Field Name
Web Parameter Name
TrunkGroup_x
[Trunk Group Table]
ChannelList
DefaultNumber
[Default Destination
Number]
ChannelSelectMode
[Channel Select Mode]
V7122 Gateway User Guide
Valid Range and Description
TrunkGroup_x = T-U/a-b,c,d
x = Trunk group ID (1 to 99).
T = Starting physical trunk number (0 to 7).
U = Ending physical trunk number (0 to 7).
a = Starting B-channel (from 1).
b = Ending B-channel (up to 31).
To represent all B-channels use a single asterisk instead of 'a'
and 'b'.
c = Phone number associated with the first channel (optional).
d = Optional Tel Profile ID (1 to 4).
For example:
TrunkGroup_1 = 0/1-31,1000
TrunkGroup_1 = 1/1-31,$$,1.
TrunkGroup_2 = 2/1-24,3000
TrunkGroup_1 = 0-7/1-20,1000
channels).
TrunkGroup_1 = 0-3/*,1000
channels).
Trunk group is the recommended method to configure the gateway's B-
channels.
An optional Tel Profile ID (1 to 9) can be applied to each group
of B-channels.
This parameter is obsolete; use instead TrunkGroup_x.
Defines the telephone number that the gateway uses if the parameters
'TrunkGroup_x' or 'ChannelList' does not include a phone number. The
parameter is used as a starting number for the list of B-channels comprising
all trunk groups in the gateway.
Defines common rule of port allocation for IP to TEL calls.
0 = By Dest Phone Number - Select the gateway port according to the
called number (see the note below).
1 = Cyclic Ascending - Select the next available channel in an
ascending cycle order. Always select the next higher channel number in
the Trunk Group. When the gateway reaches the highest channel
number in the Trunk Group, it selects the lowest channel number in the
Trunk Group and then starts ascending again (default).
2 = Ascending - Select the lowest available channel. Always start at the
lowest channel number in the Trunk Group and if that channel is not
available, select the next higher channel.
3 = Cyclic Descending - Select the next available channel in descending
cycle order. Always select the next lower channel number in the Trunk
(for E1 span).
(for T1 span).
(for 8 E1 spans, 20 B-
(for 4 E1 spans, all B-
213
