Figure 134 Prerecorded Tones Screen
To add the prerecorded tone files (you created in Step 1) to the 'Prerecorded Tones'
4
screen follow one of these procedures:
Select the files and drag them to the 'Prerecorded Tones' screen.
Click the Add File(s) button; the 'Select Files' screen opens. Select the required
Prerecorded Tone files and click the Add>> button. Close the 'Select Files' screen.
For each raw data file, define a Tone Type, a Coder and a Default Duration by
5
completing the following 6 steps:
Double-click or right-click the required file; the 'File Data' window (shown in
Figure 131) appears.
From the 'Type' drop-down list, select the tone type this raw data file is associated
with.
From the 'Coder' drop-down list, select the coder that corresponds to the coder this
raw data file was originally recorded with.
In the 'Description' field, enter additional identifying information (optional).
