E1/T1 Configuration Parameters

E1/T1/J1 Configuration Parameters
Table 45
ini File Field Name
Web Parameter Name
TDMBusType
PCMLawSelect
[PCM Law Select]
ProtocolType
[Protocol Type]
ProtocolType_x
[Protocol Type]
TraceLevel
[Trace Level]
FramingMethod
[Framing Method]
V7122 Gateway User Guide
Valid Range and Description
TP-260 only.
Must be set to 2.
1 = A-law (defaut)
3 = μ-Law
Usually A-Law is used for E1 spans and μ-Law for T1 and J1 spans.
Sets the PSTN protocol to be used for this trunk.
E1_EURO_ISDN
T1_CAS
T1_RAW_CAS
T1_TRANSPARENT
E1_TRANSPARENT_31
E1_TRANSPARENT_30
E1_MFCR2
E1_CAS_R2
E1_RAW_CAS
T1_NI2_ISDN
T1_4ESS_ISDN
T1_5ESS_9_ISDN
T1_5ESS_10_ISDN
T1_DMS100_ISDN
J1_TRANSPARENT
T1_NTT_ISDN
E1_AUSTEL_ISDN
T1_HKT_ISDN
E1_KOR_ISDN
T1_HKT_ISDN
E1_QSIG
T1_QSIG
E1_FRENCH_VN3_ISDN = 31
T1_DMS100_Meridian
E1_NI2_ISDN
The gateway simultaneously supports different variants of CAS
and PRI protocols on different E1/T1 spans (no more than four
simultaneous PRI variants).
Same as the description for parameter 'ProtocolType' for a specific trunk ID
(x = 0 to 7).
Defines the trace level.
Valid options include:
0 = No trace (default)
1= Full ISDN trace
2 = Layer 3 ISDN trace
3 = Only ISDN Q.931 messages trace
4 = Layer 3 ISDN no duplication trace
Selects the framing method to be used for E1/T1 spans.
For E1
0 = Multiframe with CRC4 (default, automatic mode, if CRC is identified in
= 1
= 2
= 3
= 4
= 5
= 6
= 7
= 8
= 9
= 10
= 11
= 12
= 13
= 14
= 15
= 16 (Japan - Nippon Telegraph)
= 17 (Australian Telecom)
= 18 (Hong Kong – HKT)
= 19 (Korean operator)
= 20 (Hong Kong - HKT over T1)
= 21
= 23
= 35
= 40
223
