C 16: C
HAPTER
This section describes the configuration (dat) files that are load (in addition to the ini file) to
the gateway. The configuration files are:
Call Progress Tones file (see
Prerecorded Tones file (see
Voice Prompts file (see
CAS protocol configuration files (see
User Information file (see
To load any of the configuration files to the gateway use the Embedded Web Server (see
Auxiliary Files) or alternatively specify the name of the relevant configuration file in the
gateway's ini file and load it (the ini file) to the gateway (see
the Device).

Configuring the Call Progress Tones

The Call Progress Tones, configuration file used by the gateway is a binary file (with the
extension dat) which contains the definitions of the Call Progress Tones (levels and
frequencies) that are detected / generated by the gateway.
Users can either use, one of the supplied gateway configuration (dat) files, or construct their
own file. To construct their own configuration file, users are recommended, to modify the
supplied usa_tone.ini file (in any standard text editor) to suit their specific requirements, and
to convert it (the modified ini file) into binary format using the TrunkPack Downloadable
Conversion Utility. For the description of the procedure on how to convert CPT ini file to a
binary dat file, see Converting a CPT ini File to a Binary dat
Only the dat file can be loaded to the gateway.
To load the Call Progress Tones (dat) file to the gateway, use the Embedded Web Server
(see Auxiliary Files) or the ini file (see
V7122 Gateway User Guide
ONFIGURATION
Configuring the Call Progress
Prerecorded Tones (PRT)
Voice Prompts File).
CAS Protocol Configuration
User Information File).
Configuration Files
F
ILES
Tones).
File).
Files).
Loading the cmp File, Booting
File.
Parameters).
391
