To remove the TP-1610 RTM from the chassis:
Remove the cables attached to the RTM.
1
Unfasten the screws on the brackets at both ends of the panel that secure the RTM to
2
the chassis.
Press the red ejector buttons on the two black ejector/injector latches on both ends.
3
Grasp the panel and ease the RTM board out of the slot.
4

Cabling the TP-1610

To cable the TP-1610:
Connect the E1/T1 trunk interfaces (see
1
Install the Ethernet connection (see
2
Optionally, connect the TP-1610 RS-232 port to your PC (see
3
Port to Your PC).
Installing the TP-260
CAUTION: Electrical Earthing
Prior to installation of any board in a chassis, always correctly connect the chassis
to a safety ground according to the laws and regulations of the country in which
the installation is performed.
Electronic components on printed circuit boards are extremely sensitive to static
electricity. Normal amounts of static electricity generated by clothing can damage
electronic equipment. To reduce the risk of damage due to electrostatic discharge
when installing or servicing electronic equipment, it is recommended that anti-static
earthing straps and mats be used.
54
Connecting the E1/T1 Trunk
Installing the Ethernet
Interfaces).
Connection).
Connecting the RS-232
