3Com V7122 User Manual page 218

ini File Field Name
Web Parameter Name
SwapRedirectNumber
[Swap Redirect and Called
Numbers]
Prefix2RedirectNumber
[Add Prefix to Redirect
Number]
AddTON2RPI
[Add Number Plan and Type
to Remote Party ID Header]
NumberMapTel2IP
[Destination Phone Number
Manipulation Table for
Tel IP calls]
218
Valid Range and Description
0 = Don't change numbers (default)
1 = Incoming ISDN call that includes redirect number (sometimes referred
as 'original called number') uses this number instead of the called number.
Defines a string Prefix that is added to the Redirect number received from
the Tel side. This Prefix is added to the Redirect Number in the Diversion
header.
The valid range is an 8-character string. The default is an empty string.
0 = TON/PLAN parameters aren't included in the RPID header.
1 = TON/PLAN parameters are included in the RPID header (default).
If RPID header is enabled (EnableRPIHeader = 1) and 'AddTON2RPI=1', it
is possible to configure the calling and called number type and number plan
using the Number Manipulation tables for Tel IP calls.
Manipulates the destination number for Tel to IP calls.
NumberMapTel2IP = a,b,c,d,e,f,g
a = Destination number prefix
b = Number of stripped digits from the left, or (if brackets are used)
from the right. A combination of both options is allowed.
c = String to add as prefix, or (if brackets are used) as suffix. A
combination of both options is allowed.
d = Number of remaining digits from the right
e = Number Plan used in RPID header
f = Number Type used in RPID header
g = Source number prefix
The 'b' to 'f' manipulations rules are applied if the called and calling numbers
match the 'a' and 'g' conditions.
The manipulation rules are executed in the following order: 'b', 'd' and 'c'.
Parameters can be skipped by using the sign '$$', for example:
NumberMapTel2IP=01,2,972,$$,0,0,$$
NumberMapTel2IP=03,(2),667,$$,0,0,22
V7122 GatewayUser Guide
