ini File Field Name
Web Parameter Name
DTMFInterDigitInterval
DTMFDigitLength
VQMonEnable
[Enable RTCP XR]
RTCPInterval
[RTCP XR Packet Interval]
DisableRTCPRandomize
[Disable RTCP XR Interval
Randomization]
RTCPXREscIP
[RTCP XR Collection Server]
RTCPXRReportMode
[RTCP XR Report Mode]

Configuration Files Parameters

The configuration files (Call Progress Tones, PRT, Voice Prompts and CAS) can be loaded
to the gateway using the Embedded Web Server (see
session.
To load the configuration files using TFTP:
In the ini file, define the files to be loaded to the device. You can also define in the ini file
1
whether the loaded files should be stored in the non-volatile memory so that the TFTP
process is not required every time the device boots up.
V7122 Gateway User Guide
Valid Range and Description
Time in msec between generated DTMF digits to PSTN side (if
TxDTMFOption = 3, 5 or 6).
The default value is 100 msec. The valid range is 0 to 32767.
Time in msec for generating DTMF tones to the PSTN side (if
TxDTMFOption = 3, 5 or 6).
The default value is 100 msec. The valid range is 0 to 32767.
Enables voice quality monitoring and RTCP Extended Reports (RTCP-
XR).
Valid options include:
0 = Disable (default)
1 = Enable
For a description of the RTCP-XR reports, see
Protocol Extended Reports (RTCP-XR)
Defines the time interval (in msec) between adjacent RTCP reports.
The interval range is 0 to 65,535. The default interval is 5,000.
Controls whether RTCP report intervals are randomized or whether each
report interval accords exactly to the parameter RTCPInterval.
Valid options include:
0 = Randomize (default)
1 = No Randomize
IP address of the Event State Compositor (ESC). The gateway sends
RTCP-XR reports using PUBLISH messages to this server. The address
can be configured as a numerical IP address or as a domain name.
Determines whether or not RTCP-XR reports are sent to the Event State
Compositor (ESC) and if so, defines the interval in which they are sent.
Valid options include:
0 = Disable (RTCP-XR reports are not sent to the ESC) -- default
1 = End Call (RTCP-XR reports are sent to the ESC at the end of each
call)
2 = End Call & Periodic (RTCP-XR reports are sent to the ESC at the
end of each call and periodically according to the parameter
RTCPInterval)
Appendix F: RTP Control
.
Auxiliary Files), or using TFTP
