ini File Field Name
Web Parameter Name
EnableAOC
TimeForReorderTone
DisconnectOnBusyTone
[Disconnect Call on
Detection of Busy Tone]
PlayBusyTone2ISDN
[Play Busy Tone to Tel]
TrunkTransferMode_X
CASTransportType
[CAS Transport Type]
210
Valid Range and Description
0 = Not used (default).
1 = ISDN Advice of Charge (AOC) messages are interworked to SIP.
The gateway supports reception of ISDN (Euro ISDN) AOC messages. AOC
messages can be received during a call (Facility messages) or at the end of a
call (Disconnect or Release messages). The gateway converts the AOC
messages into SIP INFO (during a call) and BYE (end of a call) messages
using a proprietary AOC SIP header. The gateway supports both Currency
and Pulse AOC messages.
Busy or Reorder Tone duration the CAS gateway plays before releasing the
line.
The valid range is 0 to 15. The default value is 10 seconds.
Applicable also to ISDN if 'PlayBusyTone2ISDN = 2'. Selection of Busy or
Reorder tone is done according to release cause received from IP.
0 = Do not disconnect call on detection of busy tone
1 = Disconnect call on detection of busy tone (default).
This parameter is applicable to CAS & ISDN protocols.
This parameter enables the V7122 ISDN gateway to play a Busy or a Reorder
tone to the PSTN after a call is released.
0 = Immediately sends an ISDN Disconnect message (default).
1 = Sends an ISDN Disconnect message with PI=8 and plays a Busy or a
Reorder tone to the PSTN (depending on the release cause).
2 = Delays the sending of an ISDN Disconnect message for
'TimeForReorderTone' seconds and plays a Busy or a Reorder tone to the
PSTN. Applicable only if the call is released from the IP before it reaches the
Connect state. Otherwise, the Disconnect message is sent immediately and no
tones are played.
0 = Not supported (default).
1 = Supports CAS NFA DMS-100 transfer.
When a SIP REFER message is received, the gateway performs a Blind
Transfer by executing a CAS Wink, waits for an acknowledge Wink from the
remote side, dials the Refer-to number to the switch and then releases the call.
A specific NFA CAS table is required.
2 = Supports ISDN transfer (RLT / TBCT / ECT).
When a SIP REFER message is received, the gateway performs
a transfer by sending FACILITY messages to the PBX with the
necessary information on the call's legs that are to be connected.
The different ISDN variants use slightly different methods (using
FACILITY messages) to perform the transfer.
3 = Supports CAS Normal transfer.
When a SIP REFER message is received, the gateway performs
a Blind Transfer by executing a CAS Wink, dialing the Refer-to
number to the switch and then releasing the call.
0 = Disable CAS relay (default).
1 = Enable CAS relay mode using RFC 2833.
The CAS relay mode can be used with the TDM tunneling feature to enable
tunneling over IP for both voice and CAS signaling bearers.
