V7122 Front View Component Descriptions
Table 2
Item #
Label
1
FAULT
2
3
4
5
6
T1/E1 STATUS
7
ETH
8
9
10
11
The V7122 Chassis
The V7122 chassis is an industrial platform, 19" wide, 1U high and 12" deep that houses the
TP-1610 board in its front cage, slot #1 (the lower slot) and the TP-1610 RTM in its rear
cage, slot #1 (the lower slot).
Slot # 2 in the V7122 chassis' front and rear cages can optionally be used by customers for a
CPU board.
See
Table 3
for detailed description of the chassis' LED indicators.
Chassis LED Indicators
Table 3
Location
Right side of front panel
Right side of front panel
Left side of front panel
30
Component Description
Dual AC Power LED.
cPCI board locking screws.
cPCI latches.
TP-1610 cPCI board, 16-trunk configuration.
Status LED Indicators.
E1/T1 Trunk Status LED Indicators.
Ethernet LED Indicators.
Reset button.
cPCI LED Indicators.
Power and Fan LEDs
An available cPCI slot for an optional third-party CPU board.
Color
Function
Green
The power is on.
Fan failure - indicates that any of the internal fans has significantly
Red
reduced its speed or has stopped.
Power supply failure - indicates that one of the two AC redundant
Red
power supplies is faulty or disconnected from the AC/mains outlet.
(This LED is only relevant for the dual AC power supply).
V7122 GatewayUser Guide
