Unpacking

To unpack the TP-1610:
Open the carton and remove packing materials.
1
Remove the TP-1610 board from the carton.
2
Check that there is no equipment damage.
3
Check, retain and process any documents.
4
Notify 3Com or your local supplier of any damage or discrepancies.
5
Retain any diskettes or CDs.
6

Package Contents

Ensure that in addition to the TP-1610, the package contains:
Optionally, an RTM module
CD (software and documentation)
This User Guide
The V7122 Gateway Release Notes

Installing the TP-1610

The TP-1610 cPCI board is hot-swappable and can therefore be removed from a slot (and
inserted into a slot) while the chassis is under power. It is recommended though that you
power down the chassis and read the notes before replacing the components.
Before removing or inserting boards from / to the chassis, attach a wrist strap for
electrostatic discharge (ESD) and connect it to the rack frame using an alligator
clip.
Do not set components down without protecting them with a static bag.
Inserting Boards
To insert the TP-1610 board into the chassis:
Choose an available slot in a compactPCI™ chassis and gently insert the TP-1610 board
1
into it; as the TP-1610 board is inserted, the black plastic handles, at both ends of the
board's front panel, must engage with the chassis. When the TP-1610 board is firmly
mounted into the correct position inside the chassis, the red plastic latches within each
handle self-lock (this also ensures that the TP-1610 board is properly earthed using the
chassis) and the blue hot-swap LED is lit.
Wait for the blue hot-swap LED to turn off, indicating that the board has been inserted
2
correctly and the power supply is functioning correctly.
