Attribute Attribute
Number Name
code
Acct-Session-
44
Id

RADIUS Server Messages

In Figure 79, non-standard parameters are preceded with brackets.
Accounting Example
Figure 79
Accounting-Request (361)
user-name = 111
acct-session-id = 1
nas-ip-address = 212.179.22.213
nas-port-type = 0
acct-status-type = 2
acct-input-octets = 4841
acct-output-octets = 8800
acct-session-time = 1
acct-input-packets = 122
acct-output-packets = 220
called-station-id = 201
calling-station-id = 202
// Accounting non-standard parameters:
4 23
( 9 33) h323-gw-id =
4 23
( 9 23) h323-remote-address = 212.179.22.214
4 23
( 9 1) h323-ivr-out = h323-incoming-conf-id:02102944 600a1899 3fd61009
0e2f3cc5
4 23
( 9 30) h323-disconnect-cause = 22 (0x16)
4 23
( 9 27) h323-call-type = VOIP
4 23
( 9 26) h323-call-origin = Originate
4 23
( 9 24) h323-conf-id = 02102944 600a1899 3fd61009 0e2f3cc5

Trunk to Trunk Routing Example

This example describes two gateways, each interface with the PSTN through four E1 spans.
Gateway 'A' is configured to route all incoming Tel IP calls to gateway 'B'. Gateway 'B'
generates calls to PSTN on the same E1 Trunk as the call was originally received (in
gateway 'A').
Gateway 'A' IP address is 192.168.3.50
Gateway 'B' IP address is 192.168.3.51
V7122 Gateway User Guide
VSA
Purpose
No.
other number failed)
A unique accounting
identifier – match start &
stop
Value
Sample
Format
accepted
String
1
AAA
Stop Acc
261
