Example of the IP Routing Table Screen
Figure 84
Use the 'Add a new table entry' pane to add the routing rules:
Example of IP Routing Table Configuration
Table 55
Destination IP
Destination Mask
Address
130.33.4.6 255.255.255.255
83.4.87.6 255.255.255.0
Click the Submit button to save your changes.
Save your changes to flash so they are available after a power fail, see
6
Configuration.
Reset the gateway (see
7
Integrating Using the ini File
To integrate the gateway into a VLAN and multiple IPs network using the ini file:
Prepare an ini file with parameters shown in
1
If the BootP/TFTP utility and the OAM interface are located in the same network, the
Native VLAN ID (VlanNativeVlanId) must be equal to the OAM VLAN ID
(VlanOamVlanId), which in turn must be equal to the PVID of the switch port the
gateway is connected to. Therefore, set the PVID of the switch port to 4 (in this
example).
Configure the OAM parameters (LocalOAMPAddress, LocalOAMSubnetMask and
LocalOAMDefaultGW) only if the OAM networking parameters are different from the
networking parameters used in the Single IP Network mode.
The IP Routing table is required to define static routing rules for the OAM and Control
networks since a default gateway isn't supported for these networks.
V7122 Gateway User Guide
Gateway IP
Address
10.32.0.1
10.31.0.1
Resetting the Gateway).
Figure 77
Hop Count Network Type
20 Control
20 OAM
Saving
(see the following notes):
285
